Side Tilt Carriage - There are actually 4 sizes of hook type blade carriages rated by the fork carriage lifting capacity. Hook type blade carriages have been the same.
Class I carriages are rated for loads up to 2000 lbs. The carriage bar spacing for Class I is 13 inches. Class II carriages are rated for cargo up to 5,550 lbs. Their carriage bar spacing is sixteen inches. Class III carriages are rated for loads as much as 10,000 lbs. The carriage bar spacing for this particular class is twenty inches. Class IV carriages are rated for loads as much as 15,500 lbs. The carriage bar spacing for this capacity is twenty five inches.
The carriages for pin type forks may be different depending on the maker. Pin mounted blades can differ by the amount of offset between the tine eye and the blade. Carriage capacity would be determined by the carriage pin size and by the fork size.
